Product Specification
High-Speed HDMI Cable with Ethernet (HDMI 2.0) | GET POINT Taiwan
Model: HDMIPC-20-001
Key Features
- 4K @ 60Hz resolution support
- 18 Gbps bandwidth
- Triple-layer EMI/RFI shielding
- 24K gold-plated connectors
- Ethernet channel support
- Backward compatible with HDMI 1.3/1.4
Detailed Specifications
| General Information | |
|---|---|
| Brand | Get Point Taiwan |
| Model Number | HDMIPC-20-001 |
| HDMI Version | |
| Supported Version | HDMI 2.0 (Certified) |
| Compliance Standards | HDMI 2.0 Specification, HDCP 2.2 |
| Performance | |
| Maximum Resolution | 4K @ 60Hz |
| Maximum Bandwidth | 18 Gbps |
| Backward Compatibility | HDMI 1.3, HDMI 1.4 |
| Construction | |
| Conductor Material | Oxygen-Free Copper (OFC), 99.99% Pure |
| Wire Gauge | 30 AWG |
| Shielding | Triple-layer (Aluminum Foil + Braided Shielding) |
| Connector Type | Standard HDMI (Type A) with 24K Gold Plating (3μm) |
| Physical Attributes | |
| Available Lengths | 1m, 1.8m, 3m, 5m, 10m, 15m, 20m, 30m, 50m |
| Maximum Recommended Length | 10m for full 18 Gbps performance |
| Cable Diameter | 9mm |
| Color | Black |
| Certifications | |
| Safety Standards | CE, FCC, RoHS |
| Fire Rating | VW-1 Rated |
Additional Features
- Supports Ethernet Channel for device networking
- Audio Return Channel (ARC) supported
- Corrosion-resistant tinned copper contacts
- Moderately flexible PVC jacket for tight spaces
- Operating temperature range: Up to 80°C
- Humidity resistant (5% to 95% RH non-condensing)
Warranty & Support
1-Year Warranty with free replacement during warranty period.
Email/phone support available.
Recommended Applications
- Gaming Consoles (PS5, Xbox Series X)
- Home Theater Systems
- Professional AV Equipment
- 4K/8K Projectors
- High-Resolution Monitors
